ASPIRE TRIANGLE

ASPIRE TRIANGLE 90

PRODUCT REFRENCE

ITEM CODE  ASPIRE TRIANGLE 90
ENVIRONMENT   Indoor
INSTALLATION  Suspended

CONSTRUCTION AND MATERIALS

SIZE OUT SIDE MM  1187 Dia x52x70
SIZE CUT OUT SIZE (MM)  -
HOUSING  Extruded Aluminium
LENS / DIFFUSER  High Transmission PMMA
REFLECTOR  N/A
SURFACE FINISH  White/Black/Custom Powder Coated

THERMAL MANAGEMENT

HEAT SINK MATERIAL   Aluminium
COOLING TECHNIQUE  Passive

OPTICAL SYSTEM

BEAM ANGLE  110°
ILLUMINATION MODE  Direct Lighting
SWIVEL  No

LIGHT TECHNOLOGY

LED FITTED  Bridgelux
DELIVERED LUMENS  9000 / 8550 / 8100
CCT (K)  6000 / 4000 / 3000
Tunable  On Request
LED BINNING  3 Step MacAdam
CRI (Ra)  80 / 90
LED LIFE L70  45,000 HRS
LUMINAIRE LUMINOUS FLUX  12600 / 12150 / 11700
LUMINOUS EFFICACY  100 Lumens / Watt

ELECTRICAL SYSTEM

(UGR)  <22
INPUT VOLTAGE  220 TO 240 Vac
INPUT POWER  90W
POWER FACTOR  >0.95
THD  <10%
CONTROL GEAR MOUNTING  IN BUILT
DRIVER PROTECTION  OVP,Short Circuit,Surge
DIMMING  Phase / Analog / Dali / RF / APP
EMERGENCY BATTERY BACKUP  On Request
APPLICATION AREAS:  Office buildings,Retail,Supermarkets,Hospitality,liberary
