AERO UP DOWN 60
PRODUCT REFRENCE
ITEM CODE AERO UP DOWN 60
ENVIRONMENT Indoor
INSTALLATION Suspended
CONSTRUCTION AND MATERIALS
SIZE OUT SIDE MM 2367x73x110
SIZE CUT OUT SIZE (MM) -
HOUSING Extruded Aluminium
LENS / DIFFUSER High Transmission PMMA
REFLECTOR N/A
SURFACE FINISH White/Black/Custom Powder Coated
THERMAL MANAGEMENT
HEAT SINK MATERIAL Aluminium
COOLING TECHNIQUE Passive
OPTICAL SYSTEM
BEAM ANGLE 110°
ILLUMINATION MODE Direct/Indirect Lighting
SWIVEL No
LIGHT TECHNOLOGY
LED FITTED Bridgelux
DELIVERED LUMENS 6000 / 5700 / 5400
CCT (K) 6000 / 4000 / 3000
Tunable On Request
LED BINNING 3 Step MacAdam
CRI (Ra) 80 / 90
LED LIFE L70 45,000 HRS
LUMINAIRE LUMINOUS FLUX 8400 / 8100 / 7800
LUMINOUS EFFICACY 100 Lumens / Watt
ELECTRICAL SYSTEM
(UGR) <22
INPUT VOLTAGE 220 TO 240 Vac
INPUT POWER 60W (20U+40D)
POWER FACTOR >0.95
THD <10%
CONTROL GEAR MOUNTING IN BUILT
DRIVER PROTECTION OVP,Short Circuit,Surge
DIMMING Phase / Analog / Dali / RF / APP
EMERGENCY BATTERY BACKUP On Request
